Production Introduction
Platinized titanium anode mesh is the use of electroplating/brush plating method on the standard titanium mesh to form platinum coating, improve the electrical conductivity, corrosion resistance and other physical and chemical properties of titanium mesh. The platinum-plated titanium mesh can be used in the fields of hydrogen production by electrolytic water and cathodic protection.
|
Base material |
Platinum coating |
process |
Platinum coating Thickness |
Specification |
Dimensions Current density |
|
Gr1/Gr2 titanium |
pure platinum, platinum-iridium |
plating, brush plating |
0.2 μm-10 μm |
commonly used platinum-plated titanium mesh, can also be customized according to customer needs |
≤5000 A/㎡ |
Product advantage
1. Coating method is optional. Ehisen has extensive platinum plating experience and can choose to use electroplating or brush plating according to customer requirements.
2. Good uniformity of coating. In terms of uniformity of coating, electroplating is better than brush plating, but even for platinum plating by brush plating, we can achieve a coating tolerance of ±0.2 μm.
3. Coating binding force is good. Whether it is electroplating or brush plating for platinum plating, we will test the coating binding force after production, including but not limited to bending test, wipe test and other methods.
4. Long life. Thanks to the good uniformity of the coating, the service life of our products is also guaranteed, and the specific service life can be enhanced according to the customer's use environment.
5. Look good. Our products use high purity platinum, so that the appearance of the product has a better performance, while rich production experience and perfect technical process to make the overall appearance of the product quality also ensure your satisfaction.
Parameters of platinum-plated titanium anode network
|
Plate Thickness d/mm |
Mesh Size /mm |
Mesh Size /mm |
|||
|
Mesh Width B |
Mesh Length L |
Long Pitch TB |
Short Pitch TL |
Filament Width b |
|
|
0.5~1.5 |
400~1200 |
≤2000 |
4 |
3.5 |
0.5 |
|
6.1 |
3.7 |
0.8 |
|||
|
8 |
4.5 |
1.5 |
|||
|
10 |
4.5 |
1.5 |
|||
|
10 |
5 |
1.5 |
|||
|
10.3 |
6 |
1.5 |
|||
Production process of platinum-plated titanium anode mesh
Product application
FAQ
Is it acceptable to include my logo on the item?
Yes, we can obtain OEM and ODM
Do you have titanium mesh inspection protocols?
Complete self-checking prior to packaging. For each order, we offer Quality Certification.
Are you a manufacturer or a trading company?
We are an exporter and factory.
How is the package doing?
If wire mesh, a wooden box plus a wooden pallet, or paper tubes plus plastic or bubble wrap.
Can goods be made to order?
Yes, you can modify any product to meet your specific needs.
Ehisen
Logistics freight
01
Before Delivery
We will check the quality and quantity of the goods to ensure they are correct and error-free, and then package them for shipment.
02
Before Receiving
Please inspect the packaging before signing for the goods upon receipt, and contact us promptly if there are any issues.
03
Delivery Time
We will arrange delivery within 5 working days after receiving the order.
