The company is founded in 2004 as a high-tech enterprise focused on advanced metal material production, including melting, profiling, machining, and precious metal anodes research and dewdoment with a 15 mu area and 5o employees, our company specializes in advanced manufacturing.
The company hasequipment for alloy production, rolling, heat treatment and stamping, Processing centers, electroplating, titanium anode production lines and precious metal coating laboratory, as well is related testing equipment. After years of development, it has become a comprehensive company integrating R&D, production and sales.
Why choose us
Perfect Sales Service
Ehisen provides you with one-stop non-ferrous metal production, processing, after-sales, and other supporting services
Complete Manufacturing Proficiency
Top-notch titanium items covering all grades are offered in a range of forms, such as plates, flanges, rods, bolts, and tube fittings.
Personalized Solutions For Metal Processing Products
Our unique, near-net-shape metal fabrication services can help you achieve greater value from your Metal Processing Products .
Confidentiality Advantage
After signing a confidentiality agreement, non-relevant personnel cannot enter the workshop at will, making proofing more secure.
|
Product Name |
Zirconium bar rod |
|
Standard |
1. Zirconium bar Zr702 |
|
Surface treatment |
Polishing,Sandblast,burned,anodizing ,PVD,Nitriding |
|
Features |
1. Good ductility, good machinability |
|
Applications |
Zirconium bar is used for CD-ROM, Decoration, Flat panel displays, Functional coating as nicely as other optical information storage space industry, Glass coating industry like Car glass and Architectural glass, Optical communication etc |
|
Grade |
Element composition(%)< |
||||||||
|
Zr+Hf |
Hf |
Fe+Cr |
Sn |
H |
N |
C |
Nb |
O |
|
|
R60702 |
99.2 |
4.5 |
0.2 |
-- |
0.005 |
0.025 |
0.05 |
-- |
0.16 |
|
R60704 |
97.5 |
4.5 |
0.2-0.4 |
1.0-2.0 |
0.005 |
0.025 |
0.05 |
-- |
0.18 |
|
R60705 |
95.5 |
4.5 |
0.2 |
-- |
0.005 |
0.025 |
0.05 |
-- |
0.18 |
Melting and Casting:
The purified zirconium metal is melted in a controlled environment. Once molten, it is cast into ingots or billets using molds. This step establishes the initial form of the Zirconium Rods.
Hot Working:
The cast ingots may undergo hot working processes such as forging or rolling. These processes help shape the zirconium into the desired dimensions, enhancing its mechanical properties and aligning it with specific applications.
Heat Treatment:
Heat treatment is applied to the zirconium rods to optimize their mechanical properties. This controlled process involves heating and cooling to achieve the desired hardness, strength, and microstructure.
Final Finishing:
The finished Zirconium Rods undergo final finishing processes, which may include polishing or coating for specific applications.
Quality Test of Zirconium Rod
Surface Finish Inspection
Surface finish inspection assesses the quality of the zirconium rod's surface. It involves checking for defects, roughness, or irregularities that could impact the rod's performance or aesthetics.
Dimensional Accuracy
Precise dimensional measurements verify that the zirconium rod conforms to the specified size and shape requirements. This ensures it fits its intended use and integrates easily.
Ultrasonic Testing
Ultrasonic waves are used to detect internal defects, voids, or inconsistencies in the zirconium rod. This non-destructive method provides valuable insights into the material's overall quality.
Chemical Composition
Analyzing the chemical composition verifies the purity of the zirconium rod. It ensures that the alloy composition aligns with the specified standards and meets the required criteria for the intended application.
Mechanical Properties
Testing mechanical properties includes assessing factors like tensile strength, yield strength, and elongation. These tests help determine the structural integrity and performance characteristics of the zirconium rod under different stress conditions.
Microstructure Examination
Microscopic examination of the zirconium rod's structure provides insights into grain size, uniformity, and overall microstructure. A fine and consistent microstructure contributes to enhanced mechanical properties.
Hardness Testing
Measuring the hardness of the zirconium rod is crucial for evaluating its resistance to deformation and wear. Common hardness tests include Rockwell or Vickers hardness tests.
Product Features
Superior Corrosion Resistance: Ideal for applications in aggressive chemical environments.
High Thermal Stability: Withstands extreme temperatures without compromising performance.
Excellent Biocompatibility: Perfect for medical implants and devices.
Customizable Dimensions: Tailored solutions to meet specific application requirements.
Global Standards Compliance: Manufactured to ASTM B550 and other international standards.
Applications
Aerospace and Aviation
Lightweight and durable for critical components.
01
Medical Devices
Biocompatible materials for implants and surgical tools.
02
Chemical Processing
Corrosion-resistant rods for reactors and piping systems.
03
Energy Sector
Components for nuclear reactors and renewable energy systems.
04
Marine Engineering
Saltwater-resistant materials for shipbuilding and offshore structures.
05
Our Honor
FAQ
As one of the leading zirconium manufacturers and suppliers in China, we warmly welcome you to buy or wholesale bulk high purity zirconium at competitive price from our factory. Contact us for quotation and free sample.
