Products Description
MMO tubular anodes are a corrosion protection device used in a variety of industries. It is a tubular structure coated with a durable MMO, usually iridium tantalum (IrO2 / Ta2O5) or iridium ruthenium (IrO2 / RuO2).
Their purpose is to prevent corrosion of metal structures such as pipes, tanks and bridges by creating a rust-proof electrochemical reaction, thus extending the service life of equipment.
They are known for their durability, low maintenance requirements and cost-effectiveness. They are critical to protecting critical infrastructure.
Products
Products parameters
Main Technical Parameters of MMO Tubular Anodes
| Property | Details |
| Substrate | Titanium Gr1 |
| Coating | Iridium Oxide (IrO2), Ruthenium Oxide (RuO2), Tantalum Oxide (Ta2O5) |
| Shape | Tubular |
| Length | 50-1500mm |
| Diameter | 16,19,25,32mm |
| Wall thickness | 1, 1.5, 2mm |
| Application | Deep Well, Storage Tank |
| Environment | Brackish Water, Fresh Water, Seawater, Shallow Vertical Ground bed, Soil |
| Design Life | Specified 20-100 years |
Products speciation
| Outer Diameter (mm) | Length (mm) | Pipe Wall Thickness (mm) | Weight (kg) | Surface Area (m²) | Max Output Current (A/m) | Lifespan (years) |
| 19 | 1200 | 1 | 0.305 | 0.072 | 7.2 | 20 |
| 20 | 500 | 1.5 | 0.249 | 0.039 | 4 | 20 |
| 20 | 1000 | 1.0 | 0.339 | 0.079 | 8 | 20 |
| 20 | 1000 | 1.5 | 0.498 | 0.079 | 8 | 20 |
| 20 | 1500 | 1.5 | 0.747 | 0.118 | 12 | 20 |
| 20 | 1200 | 2 | 1.02 | 0.121 | 12 | 20 |
current output
| Environment | Maximum Current Density | Lifetime* |
| Carbonaceous Backfill | 50 A/m2 | 20 years |
| Calcined Petroleum Backfill | 100 A/m2 | 20 years |
| Fresh Water | 100 A/m2 | 20 years |
| Brackish Water | 100-300 A/m2 | 20 years |
| Sea Water | 600 A/m2 | 20 years |
ehisen
Products application
application
Ground Bed (deep, Shallow, Vertical, Horizontal, Opening)
They are critical for bed installations, both deep and shallow. They perform well in vertical and horizontal orientations and in open-hole applications, providing effective corrosion protection for buried structures.
The Marine Environment
They are highly effective in marine environments, providing corrosion protection for structures such as docks, bridge piers and underwater equipment. They are compatible with a wide range of marine conditions and can withstand the challenges posed by saltwater and marine ecosystems
Water Type
They are suitable for different water types including:
Seawater: Ideal for protecting structures submerged in seawater, where corrosion is particularly severe.
Brackish Water: Effective in environments with mixtures of salt water and fresh water, providing corrosion resistance at varying salinity levels.
Mud: Suitable for installation in muddy or sediment-rich environments where other anodes may not perform as well.
Freshwater: MMO tubular anodes are ideal for freshwater applications, helping to maintain the life of river, lake and reservoir assets.
service
Our Service Processes
Inquiry
1
>>
Determine the product
2
>>
Order samples
3
>>
Confirm the order
4
>>
Multi-Channel Shipping
5
>>
After-sale Services
6
How to customize a suitable MMO tubular anode?
To ensure an optimized solution is tailored to your unique project specifications, it is critical to provide comprehensive details when ordering tubular anodes from us. Be sure to include the following key information:
Anode Specifications: Clearly define required dimensions, including length and diameter, ensuring a perfect fit for your project.
Application Environment: Clarify the intended use environment of MMO tubular anodes. This directly affects material selection and performance optimization.
Life expectancy: Communicate your life expectancy for your MMO tubular anodes so we can recommend the most appropriate configuration.
Cable Requirements: Provides details about cable requirements, including length and other relevant specifications. This facilitates seamless system integration.
Work with us by providing comprehensive information and let us assist you in customizing an MMO tubular anode that perfectly matches the unique requirements of your project.
